Description
MartinLogan Icon 3XW Architectural In-Wall Speaker overview
The MartinLogan Icon 3XW brings Masterpiece CI performance to a compact architectural format. A Folded Motion XT Obsidian tweeter, dual carbon-fibre multi-section drivers and a flagship Vojtko crossover provide high output and clarity for cinema, stereo or discreet on-wall applications using the optional frame.
Key benefits
- Compact flagship-class architectural loudspeaker
- Folded Motion XT Obsidian tweeter
- Dual carbon-fibre multi-section cone drivers
- Vojtko crossover with premium components
- Paintable micro-perforated grille
- Optional on-wall mounting frame available
Technical specifications
| Frequency Response | 78–25,000 Hz ± 3 dB |
|---|---|
| Tweeter Dispersion (horizontal x vertical) | 80° x 30° |
| Sensitivity | 94 dB @ 2.83 volts/ meter |
| Impedance | 4 ohms. Compatible with 4, 6, or 8 ohm rated amps. |
| Crossover Frequency | 2400 Hz |
| High Frequency Driver | 1.25 x 2.4 inch (3.2 x 6.1 cm) Folded Motion XT Obsidian transducer with 4.5 x 2.75 inch (11.4 x 7 cm) diaphragm. |
| Tweeter Aiming | Rotatable tweeter for horizontal or vertical installations |
| Low Frequency Driver | Two 5.25-inch (13.33 cm) black unidirectional carbon fiber multi-section cone with Nomex® backer and cast aluminum basket, sealed back chamber format. Concave dust cap. |
| Components | Custom air core coil inductors, polypropylene film capacitors, and low DF electrolytic capacitors. Thermal/current protection. |
| Suitable Amplifier Range | 20–250 watts |
| Max Power Handling | 125 watts |
| Binding Post Inputs | Push style |
| Weight | 15.5 lb (7 kg) |
| Dimensions (overall size) | 15.98 x 9.94 x 4.11 inch (405.95 x 252.6 x 104.3 mm) |
| Required Wall Opening (includes tolerance) | 14.66 x 8.64 inch (372 x 219 mm) |
| Projection From Wall Surface | 0.31 inch (7.8 mm) |
| Depth Behind Wall Surface | 3.8 inch (96.5 mm) |
| Optional Accessories | Pre-install bracket (PN: 3XWBRK) |
| South African pack type | Each |
System design considerations
Confirm room size, listening distance, channel position, amplifier compatibility, mounting or support requirements, finish and subwoofer integration before ordering. Architectural products also require verification of wall or ceiling depth and construction.
Request a quote
MartinLogan products supplied through Homemation are available on an enquiry basis. Mirror Edge Networks can confirm current South African availability, finish options, system compatibility and installation requirements. Public pricing is intentionally not displayed.
