Rotel RMB-1585 MKII overview
The Rotel RMB-1585 MKII is a five-channel Class-AB power amplifier built for demanding home-cinema systems requiring high output across every channel.
Key features
- Five channels driven at 210 watts into 8 ohms or 340 watts into 4 ohms
- Dual toroidal transformers and high-quality slit-foil capacitors
- Balanced XLR and unbalanced RCA inputs
- Rack ears included for professional installation
Technical specifications
| Product type | Five-channel power amplifier |
|---|---|
| Amplification | Class AB |
| Output, 8 ohms | 5 × 210 W, all channels driven |
| Output, 4 ohms | 5 × 340 W, all channels driven |
| Two-channel output, 4 ohms | 2 × 440 W |
| Total harmonic distortion | Less than 0.03% |
| Frequency response | 10 Hz–100 kHz, +0.1 / -0.3 dB |
| Signal-to-noise ratio | 120 dB, A-weighted |
| Gain | 26.9 dB |
| Inputs | Balanced XLR and unbalanced RCA |
| Dimensions | 431 × 237 × 456 mm (W × H × D) |
| Rack height | 5U / 221 mm front panel |
| Weight | 37.4 kg |
| Power consumption | 1,200 W |
Official Rotel product information
System design considerations
Final selection should account for loudspeaker impedance and sensitivity, required listening levels, source and streaming formats, analogue and digital connectivity, ventilation, rack space, network reliability, control-system integration and professional setup.
Request a quote
Public pricing is not displayed for this specialist range. Mirror Edge Networks can confirm the current South African configuration, finish, availability, system compatibility and installation requirements.
