Description
Anthem AVM 70 8K overview
The Anthem AVM 70 8K is a 15.2-channel A/V preamplifier and processor designed for high-performance cinema systems using separate power amplification. It combines object-based surround processing, flexible bass management and Anthem Room Correction with an HDMI platform suited to current film, gaming and streaming sources.
Key features
- 15.2 processing channels with a maximum 9.2.6 speaker configuration
- ARC Genesis room correction and web-based configuration
- Dolby Atmos, DTS:X and IMAX Enhanced processing
- Seven HDMI 2.1 inputs supporting 8K/60Hz and 4K/120Hz
- Three HDMI outputs, including eARC support
- AirPlay 2, Chromecast, Bluetooth and Spotify Connect
Technical specifications
| Processing channels | 15.2 |
|---|---|
| Maximum speaker configuration | 9.2.6 |
| HDMI inputs / outputs | 7 / 3 |
| Maximum HDMI video | 8K/60Hz or 4K/120Hz |
| Maximum output | 10.7 Vrms XLR; 11 Vrms subwoofer |
| Frequency response | 20Hz–35kHz, ±0.2dB |
| Signal-to-noise ratio | 110dB, IEC-A at 4 Vrms |
| Dimensions (H × W × D) | 15.24 × 43.18 × 36.4cm, excluding feet/cord |
| Weight | 10.1kg |
System design considerations
This component should be selected as part of the complete signal, amplification, loudspeaker and room plan. Confirm channel requirements, loudspeaker impedance, cable connections, ventilation and control compatibility before installation.
System matching and support
Mirror Edge Networks can confirm loudspeaker loading, channel allocation, source compatibility, ventilation, rack space and control-system integration before supply. Displayed online prices include VAT; free nationwide delivery is available, typically within 3–5 business days where supplier stock is available.
