Description
MartinLogan Motion C10 overview
The MartinLogan Motion C10 is a passive loudspeaker from MartinLogan. The ideal compact Center Channel option to deliver crystal clear dialogue perfectly complimenting your Motion® home theater system. The angled flippable cabinet design of Motion® C10 allows the option to angle the speaker upwards towards the listener when it is mounted on a lower shelf, helping to improve dialogue clarity. Performance and practicality were top concerns for Motion® C10, so its relatively compact size makes it compatible with more furniture options than larger designs. Mirror Edge Networks can confirm system matching, placement and installation requirements before supply.
Key benefits
- MartinLogan thin-film high-frequency technology for clarity and controlled dispersion
- Purpose-engineered drivers, cabinet and crossover for coherent performance
- Suitable for professionally planned stereo or home cinema systems
- Product selection, placement and calibration support from Mirror Edge Networks
Technical specifications
| Dimensions (H x W x D, with feet) | 7-1/4” x 19” x 11-1/2” / 18.4cm x 48.3cm x 29.3cm |
|---|---|
| Frequency Response | 63 Hz – 25 kHz / ± 3 dB |
| Tweeter Dispersion (horizontal x vertical) | 90° x 90° |
| Recommended Amplifier Power | 20 – 200 watts |
| Sensitivity | 93 dB |
| Impedance | 4 ohms |
| Crossover Frequency | 1000 Hz, 2,000 Hz (2.5-way) |
| High Frequency Driver | 1” x 1.4” (2.6 x 3.6cm) Gen2 Obsidian Folded Motion Tweeter with 9.2 in2 (59.4 cm2) diaphragm |
| Mid-Frequency Drivers | 2x 5.5” (14cm) Woven Fiberglass cones with cast polymer baskets. Non-resonant asymmetrical chamber format. Unibody cone construction. Anti-lobing 2.5-way crossover design. |
| Cabinet | Rear Ported |
| Binding Post Inputs | Custom 5-way binding posts |
| Weight | 23.5lbs / 10.7kg |
| Finish | Gloss Black, Walnut, and Satin White |
System design and installation
Final performance depends on appropriate amplification, placement, room acoustics and calibration. Mirror Edge Networks will confirm compatibility, finish availability and the complete system configuration before supply.
Mirror Edge Networks support
MartinLogan is supplied on a Request Quote basis and prices are not displayed online. Free nationwide delivery is available, typically within 3–5 business days where supplier stock and project requirements allow.
