Description
MartinLogan Motion F20 overview
The MartinLogan Motion F20 is a passive loudspeaker from MartinLogan. Motion® F20 offers excellent detail, clarity, and power in a non-imposing floorstanding package. With the incredible trifecta of the Gen2 FMT with a Woven Fiberglass midrange and dual 6.5" aluminum bass drivers, it is well equipped to take its place in any home theater or 2-channel setup. Offering more bass extension and dynamics than its smaller sibling, the Motion® F20 is the ideal sweet spot for those balancing both performance and size. Mirror Edge Networks can confirm system matching, placement and installation requirements before supply.
Key benefits
- MartinLogan thin-film high-frequency technology for clarity and controlled dispersion
- Purpose-engineered drivers, cabinet and crossover for coherent performance
- Suitable for professionally planned stereo or home cinema systems
- Product selection, placement and calibration support from Mirror Edge Networks
Technical specifications
| Dimensions (H x W x D, with feet) | 44-3/4” x 11-3/4” x 14-1/4” / 112.7cm x 29.8cm x 36.2cm |
|---|---|
| Frequency Response | 35 Hz – 25kHz / ± 3 dB |
| Tweeter Dispersion (horizontal x vertical) | 90° x 90° |
| Recommended Amplifier Power | 20 – 300 watts |
| Sensitivity | 92 dB |
| Impedance | 4 ohms |
| Crossover Frequency | 230 Hz, 2,600 Hz (3-way) |
| High Frequency Driver | 1” x 1.4” (2.6 x 3.6cm) Gen2 Obsidian Folded Motion Tweeter with 9.2 in2 (59.4 cm2) diaphragm |
| Mid-Frequency Drivers | 5.5” (14cm) Woven Fiberglass cone with cast polymer basket. Non- resonant sealed chamber format. Unibody cone construction. |
| Low Frequency Driver | 2x 6.5” (16.5cm) aluminum cones with cast polymer baskets. Non-resonant asymmetrical chamber format. Unibody cone construction. |
| Cabinet | Bottom Ported |
| Binding Post Inputs | Custom bi-amp/bi-wire capable 5-way binding posts |
| Weight | 60lbs / 27.2kg |
| Finish | Gloss Black, Walnut, and Satin White |
System design and installation
Final performance depends on appropriate amplification, placement, room acoustics and calibration. Mirror Edge Networks will confirm compatibility, finish availability and the complete system configuration before supply.
Mirror Edge Networks support
MartinLogan is supplied on a Request Quote basis and prices are not displayed online. Free nationwide delivery is available, typically within 3–5 business days where supplier stock and project requirements allow.
