Description
MartinLogan Motion F10 overview
The MartinLogan Motion F10 is a passive loudspeaker from MartinLogan. While the Motion® F10 is the smallest floorstanding model in our assortment, it offers impressive levels of detail, clarity, and dynamics that defy the expectations of its compact design. With a height of under 39", the Motion® F10 can fit into almost any decor without being overbearing. With the combination of our Gen2 FMT, Woven Fiberglass midrange, and dual 5.5" aluminum bass drivers, Motion® F10 provides an engaging listening experience for all of your favourite content. Mirror Edge Networks can confirm system matching, placement and installation requirements before supply.
Key benefits
- MartinLogan thin-film high-frequency technology for clarity and controlled dispersion
- Purpose-engineered drivers, cabinet and crossover for coherent performance
- Suitable for professionally planned stereo or home cinema systems
- Product selection, placement and calibration support from Mirror Edge Networks
Technical specifications
| Dimensions (H x W x D, with feet) | 38-1/4” x 11-1/4” x 13-1/4” / 97.1cm x 28.6cm x 7.6cm |
|---|---|
| Frequency Response | 38 Hz – 25 kHz / ± 3 dB |
| Tweeter Dispersion (horizontal x vertical) | 90° x 90° |
| Recommended Amplifier Power | 20 – 250 watts |
| Sensitivity | 92 dB |
| Impedance | 4 ohms |
| Crossover Frequency | 280 Hz, 3,000 Hz (3-way) |
| High Frequency Driver | 1” x 1.4” (2.6 x 3.6cm) Gen2 Obsidian Folded Motion Tweeter with 9.2 in2 (59.4 cm2) diaphragm |
| Mid-Frequency Drivers | 5.5” (14cm) Woven Fiberglass cone with cast polymer basket. Non- resonant sealed chamber format. Unibody cone construction. |
| Low Frequency Driver | 2x 5.5” (14cm) aluminum cones with cast polymer baskets. Non-resonant asymmetrical chamber format. Unibody cone construction. |
| Cabinet | Bottom Ported |
| Binding Post Inputs | Custom bi-amp/bi-wire capable 5-way binding posts |
| Weight | 50.5lbs / 22.9kg |
| Finish | Gloss Black, Walnut, and Satin White |
System design and installation
Final performance depends on appropriate amplification, placement, room acoustics and calibration. Mirror Edge Networks will confirm compatibility, finish availability and the complete system configuration before supply.
Mirror Edge Networks support
MartinLogan is supplied on a Request Quote basis and prices are not displayed online. Free nationwide delivery is available, typically within 3–5 business days where supplier stock and project requirements allow.
