MartinLogan Motion XT F100 overview
The MartinLogan Motion XT F100 is a passive loudspeaker from MartinLogan. Experience exceptional sound quality with MartinLogan’s Gen2 Folded Motion® XT Tweeter featuring Folded Motion® Waveguide technology seamlessly integrated into an elegant front baffle design. The Nomex®-Reinforced Kevlar® midrange offers improved resonance reduction and clarity, while the triple 6.5” aluminum woofers provide powerful and dynamic bass. Stepping up to the XT series performance upgrades with triple bass drivers makes for a compelling option for those looking for a high-performance tower speaker. The Motion® XT F100 is sure to impress in any audio setup. Mirror Edge Networks can confirm system matching, placement and installation requirements before supply.
Key benefits
- MartinLogan thin-film high-frequency technology for clarity and controlled dispersion
- Purpose-engineered drivers, cabinet and crossover for coherent performance
- Suitable for professionally planned stereo or home cinema systems
- Product selection, placement and calibration support from Mirror Edge Networks
Technical specifications
| Dimensions (H x W x D, with feet) | 47-3/4” x 12-1/2” x 15” / / / 121.3cm x 31.75cm x 34.3cm |
|---|---|
| Frequency Response | 31 Hz – 25 kHz / ± 3 dB |
| Tweeter Dispersion (horizontal x vertical) | 90° x 45° |
| Recommended Amplifier Power | 20 – 450 watts |
| Sensitivity | 92 dB |
| Impedance | 4 ohms |
| Crossover Frequency | 280 Hz, 2600 Hz (3-way) |
| High Frequency Driver | 1.25” x 2.4” (3.2 x 6.1cm) Gen2 Obsidian Folded Motion XT Tweeter with 12.4 in2 (79.8 cm2) diaphragm |
| Mid-Frequency Drivers | 6.5” (16.5cm) Nomex Reinforced Kevlar® cone with cast aluminum basket. Non-resonant sealed chamber format. Unibody cone construction. |
| Low Frequency Driver | 3x 6.5” (16.5cm)aluminum cones with cast aluminum baskets. Non-resonant asymmetrical chamber format. Unibody cone construction. |
| Cabinet | Bottom Ported |
| Binding Post Inputs | Custom bi-amp/bi-wire capable 5-way binding posts |
| Weight | 76lbs / 34.5kg |
| Finish | Gloss Black, Walnut, and Satin White |
System design and installation
Final performance depends on appropriate amplification, placement, room acoustics and calibration. Mirror Edge Networks will confirm compatibility, finish availability and the complete system configuration before supply.
Mirror Edge Networks support
MartinLogan is supplied on a Request Quote basis and prices are not displayed online. Free nationwide delivery is available, typically within 3–5 business days where supplier stock and project requirements allow.
